26
Type 8692, 8693
english
Description of System
6 INTERFACES OF THE POSITIONER FOR THE MODELS WITH
CABLE GLAND
Inputs for position or
process set-point value
4 – 20 mA
0 – 20 mA
0 – 10 V
0 – 5 V
Input for process actual value*
4 – 20 mA
Frequency
Pt100
Binary input
24 V DC
Positioner
(Cable gland)
2 binary outputs*
(as an alternative to input
for process actual value)
Analogue position feed-
back
Inputs Outputs
Sup- ply
Operation
Fig. 11: Interfaces for the model with cable gland
The positioners Type 8692 and Type 8693 are 3-wire devices, i.e. the power (24 V DC) is supplied separately from the
set-point value signal.
*Type 8693: The switch can be used to supply power to a connected sensor
