BWT AQA perla XL - List of Supplied Parts

54
EN
2 List of supplied parts
AQA perla XL duplex water softener with:
1 1.1 Microprocessor control unit with
touch panel
1.2 Two multiple-way control valves
1.3 Water meter for partially softened
water
1.4 Actuator for setting the outlet water
hardness
2 Cover
3 Integrated regenerative container with
sievebaseandoatswitchfordisplaying
a low regenerative level
4 Brine shaft with brine extraction system
5 Water outlet
6 Water inlet with non-return valve
7 Columns containing ion exchange material
8 Floorsensorfordetectingalmofmoisture
9 AQUATEST hardness tester
Optional extras(notincludedinscopeofsupply):
Order no.
Bewasol brine pump 11808
Fault message cable, 3 m 11797
Mineral metering units
BewadosPlusE3 17080
BewadosPlusE20 17081
2
1.1
3
4
7
6
5
8
1.2
-1.4
9
