BYD PMW20 - ACCELERATOR VOLTAGE DIAGNOSIS; 2.3 ACQUIRE THE VOLTAGE INFORMATION OF THE ACCELERATOR

PMW20
202
PMW20
203
MAXSLIP 1 7.0 Hz Hardware Settings
Do not adjust it
FREQSLIP 1 45 Hz Hardware Settings
Do not adjust it
MAXSLIP 2 7.4 Hz Hardware Settings
Do not adjust it
FREQSLIP 2 75 Hz Hardware Settings
Do not adjust it
MAXSLIP 3 7.3 Hz Hardware Settings
Do not adjust it
FREQSLIP 3 120 Hz Hardware Settings
Do not adjust it
MAXSLIP 4 7.3 Hz Hardware Settings
Do not adjust it
FREQSLIP 4 160 Hz Hardware Settings
Do not adjust it
MAXSLIP 0 BRK 5.0 Hz Hardware Settings
Do not adjust it
MAXSLIP 1 BRK 5.0 Hz Hardware Settings
Do not adjust it
FREQSLIP 1 BRK 45 Hz Hardware Settings
Do not adjust it
MAXSLIP 2 BRK 5.5 Hz Hardware Settings
Do not adjust it
FREQSLIP 2 BRK 80 Hz Hardware Settings
Do not adjust it
MAXSLIP 3 BRK 7.0 Hz Hardware Settings
Do not adjust it
FREQSLIP 3 BRK 120 Hz Hardware Settings
Do not adjust it
MAXSLIP 4 BRK 7.0 Hz Hardware Settings
Do not adjust it
FREQSLIP 4 BRK 160 Hz Hardware Settings
Do not adjust it
OPTION 07 LEVEL = 1 Hardware Settings
Do not adjust it
OPTION 08 LEVEL = 6 Hardware Settings
Do not adjust it
OPTION 06 LEVEL = 6 Hardware Settings
Do not adjust it
AUX VOLTAGE #1 110.00% Hardware Settings
Do not adjust it
AUX VOLTAGE #2 120.00% Hardware Settings
Do not adjust it
ADJUSTMENT #02 72% Special Adjust Do not adjust it
SET CURRENT 240 A Special Adjust Do not adjust it
SET TEMPERATURE
26℃
Special Adjust Do not adjust it
ADJUSTMENT #03 63% Special Adjust Do not adjust it
SET CURRENT PUMP 270 A Special Adjust
Do not adjust it
HIGH ADDRESS 0 Special Adjust
Do not adjust it
DITHER AMPLITUDE 2.50% Special Adjust
Do not adjust it
DITHER FREQUENCY 31.2 Hz Special Adjust
Do not adjust it
CAN BUS SPEED 125 Special Adjust
Do not adjust it
POSITIVE E.B. LEVEL = 0 Hardware Settings
Do not adjust it
TOP MAX SPEED 130 Hz Hardware Settings
Do not adjust it
TRUCK TYPE LEVEL = 1 Hardware Settings
Do not adjust it
COMPENSATION ON Hardware Settings
Do not adjust it
SLIP CONTROL ON Hardware Settings
Do not adjust it
DC-LINK COMPENS. ON Hardware Settings
Do not adjust it
CONT.CLOSED DIAG ON Hardware Settings
Do not adjust it
SAT FREQUENCY 90 Hz Hardware Settings
Do not adjust it
BRAKING MODUL. 80 Hz Hardware Settings
Do not adjust it
MINIMUM VOLTAGE 3.10% Hardware Settings
Do not adjust it
BOOST AT LO FREQ 10% Hardware Settings
Do not adjust it
BOOST AT HI FREQ 45% Hardware Settings
Do not adjust it
BOOST CORNER FRE 50 Hz Hardware Settings
Do not adjust it
BRAKING BOOSTER 0% Hardware Settings
Do not adjust it
MOTOR RESISTANCE LEVEL = 0 Hardware Settings
Do not adjust it
SLIP COEFFICIENT LEVEL = 0 Hardware Settings
Do not adjust it
MAXSLIP RESET 0.60 Hz Hardware Settings
Do not adjust it
MAXSLIP 0 7.0 Hz Hardware Settings
Do not adjust it
SM-PMW202020001-EN
SM-PMW202020001-EN
Description
Name
Current
Value
Menu
Description
Name
Current
Value
Menu
IRAP SPEED
40 Hz
Adjustment
Alarm for over speed
TEM
P
M
OT ALARM
120 ?0
Adjustment
TEMP MOT STOP 145 ?0 Adjustment
An alarm for motor temp-
erature.The driving speed
is reduced to 50% and
the lifting function is not
limited.
An a
larm for motor tempe-
rature. The driving speed
is reduced to 0 and the
lifting function is not limited.
