PMW20
201
PMW20
200
INVERSION MODE OFF Set Options
HYDRO FUNCTION NONE Set Options
Unused state. Hydraulic
auxiliary steering function
M.C. FUNCTION PRESENT Set Options
Main contactor function
PRESENT Set Options
Electromagnetic brake output
function
DISPLAY TYPE 4 Set Options
Display specification
REMA TILLER CAN ON Set Options
LIFT MODE OPTION #1 Set Options
SPEED ON MDI ON Set Options
OFF Set Options
BMS PRESENT Set Options
CONNECTED TO TRACTION Set Model
Show the function of the
current controller such as
working controller, pump
controller and eps steering
controller.
SET BATTERY TYPE 24V Adjustment Set the battery voltage
ADJUST BATTERY 26.52 V Adjustment
THROTTLE 0 ZONE 5% Adjustment
60% Adjustment
Accelerator curve setting
(acceleration rate)
40% Adjustment
Accelerator curve setting
(acceleration rate)
THROT.0 LEFT LFT 5% Adjustment
Unused
THROT.X LEFT LFT 40% Adjustment
Unused
THROT.Y LEFT LFT 60% Adjustment
Unused
THROT.0 LEFT LOW 5% Adjustment
Unused
THROT.X LEFT LOW 40% Adjustment
Unused
THROT.Y LEFT LOW 60% Adjustment
Unused
THROT.0 RIGH.LFT
5%
Adjustment
Unused
THROT.X RIGH.LFT 40%
Adjustment
Unused
THROT.Y RIGH.LFT 60%
Adjustment
Unused
THROT.0 RIGH.
LOW
5% Adjustment
Unused
THROT.X RIGH .
LOW
40% Adjustment
Unused
THROT.Y RIGH.
LOW
60%
Adjustment
Unused
BAT. MIN ADJ.
LEVEL = 3
Adjustment
BAT. MAX ADJ.
LEVEL = 5
Adjustment
BDI ADJ STARTUP
LEVEL = 5
Adjustment
CHECK UP DONE OFF Adjustment
Unused
CHECK UP TYPE NONE Adjustment
Unused
MC VOLTAGE 100% Adjustment
Initial voltage of the main
contactor
MC VOLTAGE RED. 80% Adjustment
Sustaining voltage of the main
contactor
EB VOLTAGE 100% Adjustment
Initial voltage of the brake
EB VOLTAGE RED. 80% Adjustment
Sustaining voltage of the brake
PWM EV2 100.00% Adjustment
Unused
PWM EV3 100.00% Adjustment
Unused state. Percent of the
output voltage of the lifting
solenoid valve.
CUTBACK
SENS CNT
20 Adjustment
Unused
BELLY TIME 1 Adjustment
Adjustable Belly time in reverse.
DEBOUNCING
TIME
3 Adjustment
Unused
SPEED FACTOR 213 Adjustment
Check the speed on the
display.
IRAP SPEED 40 Hz Adjustment
Alarm for over speed
SM-PMW202020001-EN
SM-PMW202020001-EN
Description
Name
Current
Value
Menu
Description
Name
Current
Value
Menu
AUX OUT
FUNCTION
Mode of the quick inversion
switch
Show if REMA CAN tiller can
be used.
Working mode of the lift motor
The speed shown on the display
RESE T
HOURMETER
Reset the Hour meter. Setting
it ON means it will reset to 0.
Select the battery type as the
lithium battery or lead battery.
Current battery voltage and
voltage between KEY and B-.
Accelerator dead zone (can be
set up arbitrarily)
THROTTLE X POINT
THROTTLE Y POINT
For the setting with lead
battery, unused state.
For the setting with lead
battery, unused state.
For the setting with lead
battery, unused state.
SPEED FACTOR 213 Adjustment
Check the speed on the display.
