C-COR Flex Max901e - Page 105

A
1502154 Rev D Comparison—Flex Max901e and 700/800/900/901 Series A-3
Table A.2 FlexNet 900/Flex Max901/Flex Max901e Trunk Comparison Specifications Summary
FlexNet 900 FlexNet 900 Flex Max901 Flex Max901e
Specification FNT94CL-xx6x1A1 FNT95DJ-xx6x1A1 FMT1G8J-xx6x1A1 FMTEG8J-xx6x1A1
Bandwidth FWD: 54–750MHz
REV: 5–40MHz
FWD: 54–870MHz
REV: 5–42MHz
FWD: 54–1002MHz
REV: 5–42MHz
FWD: 54–1002MHz
REV: 5–42MHz
Operational Gain (dB) FWD: 28 (T) & 37 (B)
REV: 18
FWD: 30 (T) & 39 (B)
REV: 18
FWD: 33 (T) & 43 (B)
REV: 18
FWD: 33 (T) & 43 (B)
REV: 18
Operational O/P Levels
(dBmV)
FWD: 38.5/26 (T) & 47.5/35 (B)
REV: 35/35
FWD: 40.5/26 (T) & 49.5/35 (B)
REV: 35/35
FWD: 43/33 (T) & 53/35(B)
REV: 35/35
FWD: 42/32 (T) & 52/35(B)
REV: 35/35
Factory Cable, dB 17 (T) & 17 (B) @ 750MHz 18 (T) & 18 (B) @ 870MHz 13 (T) & 23 (B) @ 1002MHz
13 @ 1002MHz
CTB,–dBc (79 CH w/ SDL) 82 (T) & 70 (B) 81 (T) & 69 (B) 82 (T) & 75 (B)
84(T) & 75 (B)
CSO,–dBc (79 CH w/ SDL) 73 (T) & 66 (B) 79 (T) & 73 (B) 76 (T) & 73 (B)
79 (T) & 73 (B)
XMD, –dB (79 CH w/ SDL) 79 (T) & 67 (B) 76 (T) & 66 (B) 73 (T) & 67 (B)
76 (T) & 67 (B)
CIN, –dBc (79 CH w/ SDL) 85 (T) & 68 (B) 82 (T) & 65 (B) 80 (T) & 65 (B)
1002MHz: 80 (T) & 66 (B)
870MHz: 86 (T) & 72 (B)
CNR, 4 MHz, dB 60.5/60 (T) & 60.5/60 (B) 60/59 (T) & 60/59 (B) 60/58 (T) & 60/58 (B)
59/57.2 (T) & 59/57.2 (B)
Flatness @ GS, dB 1.0 P–V (T) & 1.5 P–V (B) ±0.5 (T) & ±0.75 (B) ± 0.75 (T) & ±1.0 (B)
± 0.75 (T) & ±1.0 (B)
FWD Testpoints, dB I/P: –20 ± 0.75
O/P: –20 ± 0.5
I/P: –20 ± 0.75
O/P: –20 ± 0.5
I/P: –20 ± 1.0
O/P:–20 ± 0.5 (54-550) &
–20 ± 1.0 (551-1002)
I/P: –20 or –25 ± 1.0
O/P:–20 or –25
± 0.5 (54-550) &
–20 or –25 ± 1.0 (551-1002)
REV Testpoints, dB I/P & O/P: –20 ± 0.5 I/P & O/P: –20 ± 0.5 I/P & O/P: –20 ± 0.5
I/P & O/P: –20 & –25 ± 0.5
AC Power, W (Max) 54 @ 90V 53.5 @ 90V 53.5 @ 90V
53.5 @ 90V
Table A.3 FlexNet 900/Flex Max901/Flex Max901e Bridger Comparison Specifications Summary
FlexNet 900 FlexNet 900 Flex Max901 Flex Max901e
Specification FNB96CL-xx6x1A1 FNB9ADJ-xx6x1A1 FMB1GPJ-xx6x1A1 FMBEGPJ-xx6x1A1
Bandwidth FWD: 54–75 MHz
REV: 5–40MHz
FWD: 54–870MHz
REV: 5–42MHz
FWD: 54–1002MHz
REV: 5–42MHz
FWD: 54–1002MHz
REV: 5–42MHz
Operational Gain (dB) FWD: 37
REV: 18
FWD: 40
REV: 18
FWD: 43
REV: 18
FWD: 43
REV: 18
Operational O/P Levels
(dBmV)
FWD: 47.5/35
REV: 35/35
FWD: 49.5/35
REV: 35/35
FWD: 53/35
REV: 35/35
FWD: 52/35
REV: 35/35
Factory Cable, dB 17 @ 750MHz 18 @ 870MHz 23 @ 1002MHz
23 @ 1002MHz
CTB,–dBc (79 CH w/ SDL) 70 70 75
75
CSO, –dBc (79 CH w/ SDL) 66 70 73
73
XMD, –dB (79 CH w/ SDL) 67 69 67
67
CIN, –dBc (79 CH w/ SDL) 68 65 72
1002MHz: 73
870MHz: 79
CNR, 4 MHz, dB 60/58 58.5/58 58/57
59/59.1
Flatness @ Gain Slope, dB 1.5P–V ±0.75 ±1.0
±1.0
FWD Testpoints, dB I/P: –20 ± 0.75
O/P: –20 ± 0.5
I/P: –20 ± 0.75
O/P: –20 ± 0.5
I/P: –20±1.0
O/P: –20 ± 0.5 (54–550) &
–20 ± 1.0 (551–1002)
I/P: –20 or –25 ± 1.0
O/P:–20 or –25
± 0.5 (54-550) &
–20 or –25 ± 1.0 (551-1002)
REV Testpoints, dB I/P & O/P: –20 ± 0.5 I/P & O/P: –20 ± 0.5 I/P & O/P: –20 ± 0.5
I/P & O/P: –20 & –25 ± 0.5
AC Power, W (Max) 48.5 @ 90V 48.0 @ 90V 45.5 @ 90V
45.5 @ 90V
