B
1502154 Rev D Specifications B-3
Powering Requirements, Max./Typ.
17
With Active Return
AC Voltage, 60Hz @ 90V @ 60V
AC Power, Watts 53.5/49 53/48
AC Current, mA 735/700 970/880
DC Current, mA @ 24V ± 0.5V 1955/1775 1955/1775
Level Control
Range, dB @ 1002MHz +4/–5dB —
Accuracy (–40 to 60°C) ±0.5dB —
Output Level Range
18
(from nominal) +5/–3dB —
Pilot Frequency Band
19
(recommended) 499.25MHz (Single Channel) —
Gain Control
Plug-in PAD NPB–XXX NPB–XXX
Equalization to Compensate for Cable Loss
Plug-in Equalizers for Additional
Equalization
SEQ–1G–XX MEQ–42–XX
Chrominance/Luminance Delay, Max.
Channel 2, ns/3.58MHz 33 —
Channel 3, ns/3.58MHz 14 —
Channel 4, ns/3.58MHz 7 —
Channel 5, ns/3.58MHz 3.6 —
Return Group Delay, Max.
5.5–7MHz, ns — 52
10–11.5MHz, ns — 6
35–36.5MHz, ns — 10
38.5–40MHz, ns — 19
Hum Modulation (Time Domain @ 15A)
5–10MHz, –dBc — 55
11–750MHZ, –dBc 60 60
751–1002MHz, –dBc 55 —
Specification Document Number 1502212 Rev C
1. Spacing at highest frequency with SEQ–1G–XX installed. Return spacing includes losses due to housing, diplex
filters, and MEQ–42–X.
2. The specifications are based on the amplifier configured (with two SPB–0) as a 2–output bridger with distribution
outputs on Ports 3 and 6. When using distribution plug-ins SS–1000–2, SDC–1000–8 or SDC–1000–12, levels
should be derated accordingly based on the accessory specifications.
3. NTSC video channels occupying the appropriate frequency spectrum per specified number of channels.
4. Recommended minimum forward input levels at 1002MHz including loss due to equalizer.
5. Recommended maximum return output level at 42MHz including loss due to equalizer.
6. Bridger output: At specified operational tilt the maximum output level for 870MHz or 1002GHz loading is
56.5dBmV @ HF.
7. Distortion performance is derated accordingly to take into account the influence of the digitally compressed
channels operating at levels 6dB below equivalent video channels.
8. Cross modulation specification number indicates typical cascade performance.
9. Systems operating with digitally compressed channels or equivalent broadband noise from 550 to 1002MHz at
levels 6dB below equivalent video channels will experience a composite distortion (CIN) appearing in the 54 to
550 frequency spectrum.
Table B.1 Flex Max901e Trunk Amplifier, 1002MHz, 42/54 Split, 33dB Spaced, Different Tilt on Trunk
and Bridger (cont’d)
FORWARD RETURN
Trunk 2 O/P Bridger Trunk & 2 O/P Bridger
