Tools and Materials
The following tools may be used to complete the procedures in this chapter.
Table 6.1 Tools Required
Tools/Equipment Required Specifications Uses
Signal level meter (SLM) 5MHz to 1002MHz, –35 to 60dBmV
(25 to 120dBµV)
Input and output signal testing during
forward and return balancing
Signal generator 5 to 100MHz, 10 to 60dBmV (70 to
120dBµV)
Signal input during return balancing
Multimeter True RMS, AC-coupled; ranges: 0 to
200V
DC, 0 to 200VAC, and 0 to
200mV
AC
Power supply testing
Flat blade screwdrivers 1/4 inch, 5/16 inch May be required for small fasteners
Wire cutters — Trim coaxial cable center conductor
Nutdriver or wrench
1
1. An 11mm tool can normally be used for a 7/16-inch bolt unless the tool is manufactured to minimum, and the
bolt head to maximum, “across the flat” dimensions.
7/16 inch (11mm) Housing opening and closing
Phillips screwdriver
2
2. Small, hold-down screws may be Phillips head screws or Torx PLUS
®
head screws. Use the appropriate driver.
#2 Centerseizure and module faceplate
screws; power supply and
transponder hold-down screws
Torque wrench/driver Up to 66 in-lbs (7.5N·m), with
interchangeable 7/16 inch or 11mm hex
socket, Phillips, flat blade, and Torx
®
or
Torx PLUS
®
bits
Strand mounting, housing closing,
tightening various fasteners
3
3. C-COR recommends torquing all bolts and screws to the specified values.
Torx
®
or Torx PLUS
®
driver
2
T15 (Torx
®
) or 15 I.P. (Torx PLUS
®
) May be required for small fasteners
Tuning wand Non-conductive Adjust ALC sensitivity and modulation
depth
