5-10 Flex Max901e 1GHz Trunk and Bridger Amplifiers 1502154 Rev D
Flex Max901e Trunk Amplifier with Optimized Tilt for 1GHz Operation with Trunk
and Bridger Legs at Different Output Tilts
1. Ensure that a GEQL-1GHZ-090 (9dB) is installed in the BRIDGER EQ/PAD location.
2. Ensure that NPB-000 (0dB) PADs are installed in the following locations:
– INTERSTAGE PAD
– O/P EQ
– P5/P6 FWD PAD
3. Do not remove the jumper installed in the INTERSTAGE EQ location.
Figure 5.4
Flex Max901e trunk
amplifier configured
for 1GHz operation
with trunk and
bridger at different
tilts
Note The following example is how this Flex Max901e is shipped from the factory.
DANGER
HIGH
VOLTAGE
DANGER
HIGH
VOLTAGE
DANGER
HIGH
VOLTAGE
DANGER
HIGH
VOLTAGE
PORT 1
PORT 3
PORT 2
PORT 6
DISTRIBUTION
PORT 5/6 FWD
O/P TP
PORT 2/3 FWD
O/P TP
PORT 5/6 REV
I/P TP
PORT 2/3 REV
I/P TP
MODULE
HOLD DOWN
MODULE
HOLD DOWN
P5/P6 FWD
PAD
POWER
PLUG
UNPLUG POWER SUPPLY
CONNECTOR BEFORE
REMOVING RF MODULE
BRIDGER
EQ/PAD
ALC PAD
ALC
SENSITIVITY
TRANSPONDER
PORT 5
PORT 4
PORT 1
FWD
I/P TP
PORT 4
FWD
O/P TP
STATION
FWD PAD
STATION
REV PAD
STATION
FWD EQ
STATION
REV EQ
EQ
PORT 1 REV
O/P TP
PORT 4 REV
I/P TP
MODULE
HOLD DOWN
MODULE
HOLD DOWN
15
AMPS
15
AMPS
15
AMPS
15
AMPS
DANGER
HIGH
VOLTAGE
DANGER
HIGH
VOLTAGE
CAUTION
ALC
MAN
FLEX MAX
FM901e AMPLIFIER
DISTRIBUTION
PAD
O/P EQ
INTERSTAGE
A
SLOT
B
B
SLOT
A
LE9
0JMP
0JMP
0JMP
NPB-000 PAD
NPB-000 PAD GEQL-1GHz-090
