1502154 Rev D Configuration 5-9
Factory-Shipped Configurations for Flex Max901e Trunk and Bridger Amplifiers
The information in this section details the factory-shipped configurations for 1 GHz and 870 MHz
operation for Flex Max901e trunks and bridgers when upgrading from FlexNet 900 amplifiers. To
display or discuss every possible upgrade scenario is beyond the scope of this publication. If you are
upgrading from the 700, 800, or 900 series amplifiers, contact your C-COR sales professional to
ensure you are configuring your Flex Max901e amplifiers correctly.
Flex Max901e Trunk Amplifier with Optimized Tilt for 1GHz Operation with Trunk and Bridger
Legs at Different Output Tilts—page 5-10
Flex Max901e Trunk Amplifier Configured for 1GHz Operation with Equal Output Tilt on the
Trunk and Bridger Legs—page 5-11
Flex Max901e Trunk Amplifier Configured for 870MHz operation with 14.5dB Output Tilt—page
5-12
Flex Max901e Bridger Amplifier Configured for 1GHz Operation—page 5-13
Flex Max901e Bridger Amplifier Configured for 870MHz Operation—page 5-14
