1502154 Rev D Introduction 1-5
Flex Max901e Bridger Amplifiers
1 2 3 4 5 6 7 8 9 10 11 12
FMBEGPx–xxxxxxxN
1 Series
E Flex Max901e series a
a) 15A current passing capability.
2 Bandwidth
G
1002MHz
3 Spacing
P
43dB
a
a) 23dB factory equalization.
4 Frequency Split
J
42/54MHz
N
65/85MHz
Q
55/70MHz
5–6 Level Control
K0 427.25MHz NTSC TV
KB 439.25 MHz NTSC TV
KC 451.25MHz NTSC TV
KL 423.25MHz NTSC TV
KN 471.25MHz NTSC TV
L0 499.25MHz NTSC TV
L4 495.25MHz NTSC TV
MB 645.00MHz QAM
RM 711.00MHz QAM
SD 609.00 MHz QAM
7 Return
6
18dB active gain a
7
18dB active gain with return switches b
a) Select "7" if future element management transponder is planned.
b) Operation of return switches requires a transponder.
8 Output Configuration
E Two bridger outputs—user-configurable to
4 outputs with –25dB External testpoints
a, e
G Two bridger outputs—user-configurable to
4 outputs with –20dB Internal testpoints
b, e
N Two bridger outputs—user-configurable to
4 outputs with –20dB External testpoints
c, e
R Two bridger outputs—user-configurable to
4 outputs with –25dB Internal testpoints
d, e
a) Select "A", " F", or "L" in #10 block, Housing.
b) Select "A", " C", or "K" in #10 block, Housing.
c) Select "A", " F", or "L" in #10 block, Housing.
d) Select "A", " C", or "K" in #10 block, Housing.
e) Plug-in splitters and directional couplers must be ordered
separately.
9 Powering
1
None a
6
2.3A, 90V, 50/60Hz, H.E. transformerless
b
a) Select "A" in #10 block, Housing. Required when ordering
RF module only.
b) 40–90 V operating range; includes detachable power cable.
10 Housing
A
None
a
C
6-Port Flex Max, 1GHz, w/ Internal testpoints
b
F
6-Port Flex Max, 1GHz, w/ External testpoints
c
K 6-Port Flex Max, 1GHz, four 90° access ports, w/ Internal
testpoints
b
L 6-Port Flex Max, 1GHz, four 90° access ports, w/ External
testpoints
c
a) Select "1" in #11 block, Housing Finish. Required when ordering
RF module only.
b) Select "G" or "R" in #8 block, Output Configuration.
c) Select "E" or "N" in #8 block, Output Configuration. Forward
testpoints only.
11 Housing Finish
1
Standard (or N/A)
a
4
Corrosion protected
a) Required when ordering RF module only.
12 Element Management
N EMS capable a, b
a) Transponder sold separately:
AM protocol (P/N 810-0354-01A)
HMS protocol (P/N 810-0354-01H)
b) Must order mounting bracket kit (P/N 1501024)
