C-COR Flex Max901e - Wall Mounting with Embs

4
1502154 Rev D Housing Instructions 4-13
Figure 4.7
Wall Mounting with
EMBs
Wall
Mounting
Bolt
Top Strand Clamp
Boss
Extension Mounting Bracket
1/2-inch
EMB Bolt
3.2-inch (8cm) EMB (P/N 172187-01)
6-inch (15cm) EMB (P/N 172187-03)
Lock
Washer
Flat
Washer
Nut
Lock
Washer
8.5 in.
(21.6cm)
