1502154 Rev D Specifications B-27
Powering Requirements, Max. /Typ.
16
With Active Return
AC Voltage, 60Hz @ 90V @ 60V
AC Power, Watts 45.5/41 45/40
AC Current, mA 670/630 820/740
DC Current, mA @ 24V ± 0.5V 1650/1475 1650/1475
Level Control
Range, dB @ 1002MHz +4/–5dB —
Accuracy (–40 to 60°C) ±0.5dB —
Output Level Range
17
(from nominal) +5/–3dB —
Pilot Frequency Band
18
(recommended) 499.25MHz (Single Channel) —
Gain Control
Plug-in PAD NPB–XXX NPB–XXX
Equalization to Compensate for Cable Loss
Plug-in Equalizers for Additional Equalization SEQ–1G–XX MEQ–65–XX
Chrominance/Luminance Delay, Max.
Channel S2, (PAL), ns/4.43MHz 5 —
Channel S3, (PAL), ns/4.43MHz 4 —
Channel 95, (NTSC), ns/3.58MHz 10 —
Channel 96, (NTSC), ns/3.58MHz 7 —
Return Group Delay, Max.
5.5–7MHz, ns — 52
10–11.5MHz, ns — 8
62–63.5MHz, ns — 21
63.5–85MHz, ns — 34
85-86.5MHz, ns — 13
86.5-88MHz, ns — 11
Hum Modulation (Time Domain @ 15A)
5–10MHz, –dBc — 55
11–750MHZ, –dBc 60 60
751–1002MHz, –dBc 55 —
Specification Document Number 1502530 Rev B
1. Spacing at highest frequency with SEQ–1G–XX installed. Return spacing includes losses due to housing, diplex
filters, and MEQ–55–XX.
2. The specifications are based on the amplifier configured (with two SPB–0) as a 2–output bridger with distribution
outputs on Ports 2 and 3. When using distribution plug-ins SS–1000–2, SDC–1000–8 or SDC–1000–12, levels
should be derated accordingly based on the accessory specifications.
3. NTSC video channels occupying the appropriate frequency spectrum per specified number of channels.
4. Recommended minimum forward input levels at 1002MHz including loss due to equalizer.
5. Recommended maximum return output level at 55MHz including loss due to equalizer.
6. At specified operational tilt maximum output level for 870MHz or 1GHz loading is 56.5dBmV at HF.
7. Distortion performance is derated accordingly to take into account the influence of the digitally compressed
channels operating at levels 6dB below equivalent video channels.
8. Cross modulation specification number indicates typical cascade performance.
Table B.9 Flex Max901e Bridger Amplifier, 1002MHz, 65/85 Split (cont’d)
FORWARD RETURN
2O/P Bridger 2O/P Bridger
