B-30 Flex Max901e 1GHz Trunk and Bridger Amplifiers 1502154 Rev D
Table B.11 Value Max Transponder Specifications
Characteristic Specification
Receiver Specifications
Frequency Range Agile, 48 to 162MHz
Frequency Resolution 0.1MHz steps
Modulation Type FSK
Modulation Tolerance ±2kHz
Frequency Deviation ±50kHz or ±67kHz
Data Rate 38.4kbps
Data Format asynchronous, NRZ, burst packet
Input Levels
Maximum +20dBmV
Nominal 0dBmV
Minimum –20dBmV
Input Return Loss (75 Ohms) 14dB, 50 to 1002MHz
Interference Rejection ±300kHz, 0dB
±600kHz, 20dB
Spurious Outputs –15 dBmV max., 50 to 1002MHz
Transmitter Specifications
Frequency Range Agile, 5 to 21MHz
Tuning Resolution 0.1MHz steps
Frequency Tolerance 0.01%, unmodulated mark
Modulation Type FSK
Modulation Tolerance ±2kHz
Frequency Deviation ±50kHz or ±67kHz
Data Rate 38.4kb/s
Data Format asynchronous, NRZ, burst packet
Output Levels
Maximum +40dBmV, ±3dB (0dB attenuation)
Minimum +10dBmV, ±3dB (30dB attenuation)
Output Attenuator 0 to 30dB in 2dB steps, ±1dB
Bandwidth 300kHz @ –40dB
500kHz @ –50dB
Output Return Loss (75 Ohms) 14dB, 5 to 42MHz
Spurious Outputs –55dBc max. relative to transponder transmit carrier or
–15dBmV max., 5 to 88MHz (referred to a 6MHz measurement
bandwidth)
Low Frequency Disturbances (LFD),
defined as power supply switching
frequency, etc., below band spurious that
may have harmonics to high frequencies.
<–65dBc with transponder installed.
Note: This is different from single in-band spurious requirement
because these spurs are closely spaced.
