1502154 Rev D Housing Instructions 4-3
Figure 4.1
Housing Inspection
(Outside)
Lid Bolts
Cable
Entry Ports
Convection
Fins
Back View
Front View
Bypass
6-Port Housing
Optional
External
Testp oin ts
Wall Mount
Bosses
Back View
Front View
Top Strand
Mount
Bosses
Standard
6-Port Housing
(Internal Testpoints)
(External Testpoints)
