C-COR Flex Max901e - Page 45

4
1502154 Rev D Housing Instructions 4-9
Figure 4.5
Strand/Pedestal
Mounting with EMBs
Lock
Washer
Nut
1-inch
Clamp Bolt
Strand Clamp Orientation
for 1/4-inch Strand or Smaller
Strand Clamp Orientation
for 5/16-inch Strand or Larger
Strand Clamp
1/4-inch
Strand
1/2-inch
EMB Bolt
Lock
Washer
O-Ring
(retaining)
EMB
Lock
Washer
Nut
1-inch
Clamp Bolt
Strand Clamp
5/16-inch
Strand
1/2-inch
EMB Bolt
Lock
Washer
O-Ring
(retaining)
EMB
Top
Strand
Clamp
Boss
To p S t ra nd
Clamp
Boss
