1502154 Rev D Housing Instructions 4-11

Figure 4.6

Wall Mounting with

Wall Mount Bosses

Wall

Flat Washer

Mounting Bolt

Wall Mount Boss

11.8 in.

(30.0cm)

Lock Washer
