B-8 cab - Produkttechnik GmbH
External error
There is an error at the connected applicator or in the whole process.
The print job will be broken and at the display of the printer the error message
'Host stop / error' will be shown.
After removing the error the last label will be printed again.
The error activates the signal 'Printer not ready', too.
The signal is active in the live mode of the input circuit (pin 6, pin 13).
Label was taken
The printer gets the information that the connected applicator has taken the
printed label from the peel position (a new label may be printed).
This signal is active in the live mode of the input circuit (pin 7, pin 14).
Print start
This releases the start of the print if :
- there is no label in the peel position
- a print job was sent to the printer
- the printer is ready
The signal is active in the live mode of the input circuit (pin 8, pin 15)
Warning transfer ribbon end
Message of the warning sensor transfer ribbon end.
The diameter of the ribbon supply roll has decreased below the adjusted
minimum value.
If the signal is active, the relay in the output circuit is closed.
Warning label end
Message of the warning sensor label end.
The diameter of the label supply roll has decreased below the adjusted
minimum value.
If the signal is active, the relay in the output circuit is closed.
Label in present position
A printed label is in the present position.
Message for the connected applicator to start the labelling process.
If the signal is active, the relay in the output circuit is closed.
