CAB Hermes Series User Manual

40 cab - Produkttechnik GmbH
1 2 3 4
Fig. 8 b cab-Applicators for Hermes
cab offers a own line of applicators (1) for the printers of the Hermes family. To
connect these applicators the cab-types of Hermes have aditionally a second
peripheral port (3) at the front side.
Typically for the cab-applicators, the dispensed label will be taken by a vacuum
plate (2). After that different pneumatic cylinders move the plate to the labelling
position where the label will be pressed or blown onto the product.
The size of the vacuum plate is specified for the label size.
cab-Applicators

CAB Hermes Series Specifications

General

Display	LCD with backlight
Cutter	Optional
Dispenser	Optional
Print Technology	Thermal Transfer
Resolution	203 dpi, 300 dpi, 600 dpi (depending on the model)
Interfaces	USB, Ethernet, Serial
Memory	64 MB RAM, 128 MB Flash
Media Types	Labels, continuous media
Supported Barcode Types	Data Matrix, QR Code
Max Print Width	4.09 inches (104 mm)
