44 cab - Produkttechnik GmbH

Feet

Using the profile feet Hermes can be put directly on a table. Its also possible to

mount the printer onto a customer specific head plate.

The feet are fixed from below with four screws at the frame of the printer. The

shorter foot has to be mounted below the print machanism.

Fig. 8 f Feet

Fig.8 g Set up the printer on a table

Fig. 8 h Set up the printer on a head plate
