Calrec Apollo - APOLLO INTRODUCTION

CALREC Putting Sound in the Picture 11
Ø 8.5mm
1051 [41.38”]
570 [22.44”] 600 [23.62”]
700 [27.56”]FADER LEVEL
703 [27.68”]
853.9 [33.62”]
FIGURE 4 - REDUCED HEIGHT FLOOR STAND, INLINE BOLT-DOWN FIXINGS
FIGURE 3 - STANDARD HEIGHT, INLINE BOLT-DOWN FIXINGS
Ø 10mm
ADJUSTABLE FEET
