Calrec Apollo - Port Lists

56 APOLLO Digital Broadcast Production Console Connection Information
All RTW meters have 8 analogue inputs
as well as digital I/O.
RTW METER ANALOGUE INPUTS
Analogue Inputs Pins
1
+ 24
- 12
Ground 25
2
+ 10
- 23
Ground 11
3
+ 21
- 9
Ground 22
4
+ 7
- 20
Ground 8
5
+ 18
- 6
Ground 19
6
+ 4
- 17
Ground 5
7
+ 15
- 3
Ground 16
8
+ 1
- 14
Ground 2
RTW meters
RTW meters can be supplied with
either balanced or unbalanced AES I/O.
Unbalanced versions are wired out to
BNC connectors on the rear interface.
Balanced versions are wired to a D25
connector pinned out as below:
RTW METER DIGITAL I/O
Digital Inputs Pins
1
+ 24
- 12
Ground 25
2
+ 10
- 23
Ground 11
3
+ 21
- 9
Ground 22
4
+ 7
- 20
Ground 8
Digital Outputs Pins
1
+ 18
- 6
Ground 19
2
+ 4
- 17
Ground 5
3
+ 15
- 3
Ground 16
4
+ 1
- 14
Ground 2
