74 APOLLO Digital Broadcast Production Console Setup and Configuration
This section covers areas often
required by installation engineers
to carry out the initial setup and
configuration that is required to
test the installation and provide a
starting template for operators to
work with.
Please refer to the console operator
manual and the H20 user guide for more
comprehensive information on user
functionality.
The console PC should boot from power
on, the default Windows user is 'calrec'
and requires no password. Once logged
in, the Calrec Main Application should
start up. If the Main Application is closed,
it can be restarted from the Windows
Start menu. Once open, the main pages
can be selected by clicking on their icons
across the bottom of the GUI. Most pages
have sub-pages which can be accessed
by the menu buttons at the left hand side
of each main page. Some settings within
the Main Application are protected and to
make changes the user must be logged
in as a Technician. Technician access is
gained from the Tech page by clicking
on Technician. If no users have been
setup, the system allows the creation of a
supervisor login. Supervisors are able to
create and delete other technician user
logins.
H20 - Hydra2 Organiser is an
administrator level GUI that provides
control over the whole network. H20
can be accessed via a web browser
running on a PC connected to the Master
Router. This can be a console PC (if the
master router core has a console directly
attached to it), or a PC connected directly
to a spare RJ45 on the front of the active
Control processor card in the Master
Router core. H20 is fully supported by
Google Chrome which is pre-installed on
Calrec supplied PC's with a bookmark
OVERVIEW AND GUI ACCESS
to the H20 address (IP address of the
Control processor)
Once open, H20 screens are accessed
using the menu across the top of the GUI
window.
Some features, such as accessing the
Calrec program updater and admin level
Windows settings require the user to log
into Windows as an administrator. The
user CalrecAdmin is setup up with the
password calrec.
