CALREC Putting Sound in the Picture 13
Each frame section is as wide as the
modules it can contain, (2 section -
500mm, 2.5 section - 630mm, 3 section
- 750mm, 3+ section - 760mm) plus a
3mm wide bulkhead at either end. Once
assembled, the overall chassis is fitted
with a side trim at each end. The standard
trim is 50mm, adding 100mm [3.94'] to
the overall width of the control surface.
Consoles without a floor stand can be
supplied with optional 10mm [0.39'] wide
side trims instead if physical space is
limited. Note however that the PC monitor
mount cannot be fitted to the 10mm wide
trim, therefore a suitable alternative will
need to be provided by the installers to
give the operator a conveniently located
PC monitor display.
A standard chassis build is fitted with
a PC monitor and keyboard tray at the
right hand side of the control surface. As
an option, these can be fitted at the left
hand side. If required, monitor mounts
and keyboard trays can be fitted at both
ends of the console. One of these would
typically be used as a convenient location
to control / display other equipment such
as playout devices.
FIGURE 7 - TYPICAL CONTROL SURFACE WIDTH DIMENSIONS
Fader
Count
Section
Make-up
Max Surface Width, including
50mm trim at each end
Max Surface Width, including
10mm trim at each end
(no monitor mount)
Internal Leg* External Leg*
32 2/2.5 1242mm [48.90'] 1162mm [45.75'] 1042mm [41.02'] 1212mm [47.72']
48 2/2.5/2 1748mm [68.82'] 1668mm [65.67'] 1548mm [60.04'] 1718mm [67.64']
56 3/2.5/2 1998mm [78.66'] 1918mm [75.51'] 1798mm [70.79'] 1968mm [77.48']
64 3/2.5/3 2248mm [88.50'] 2168mm [85.35'] 2048mm [80.63'] 2218mm [87.32']
72 3/3+/3 2378mm [93.62'] 2298mm [90.47'] 2178mm [85.75'] 2348mm [92.44']
72 2/3/2.5/2 2504mm [95.58'] 2424mm [95.43'] 2304mm [90.71'] 2474mm [97.40']
80 3/2/2.5/3 2754mm [108.43'] 2674mm [105.28'] 2554mm [100.55'] 2724mm [107.24']
*Internal / external leg widths do not include the floor fixing plates fitted on OB version.
