CONNECTING TO THE PC AND POWERING UP
Use this procedure to connect a management PC directly to the ePMP for configuration and
alignment purposes and to power up the ePMP device.
Procedure:
1
Check that the device and power supply are correctly connected (the device Ethernet port is
connected to the power supply Ethernet power port – see the ePMP Installation Guide for
more information).
2
Connect the PC Ethernet port to the LAN (AP: “Gigabit Data”, SM: “10/100Mbit Data”) port
of the power supply using a standard (not crossed) Ethernet cable.
3
Apply mains or battery power to the power supply. The green Power LED must illuminate
continuously.
Note
If the Power and Ethernet LEDs do not illuminate correctly, see Testing hardware on page 296.
