Cambium Networks ePMP 1000 User Manual

CAMBIUM NETWORKS
026v003
63
EPMP 1000 CONNECTORIZED RADIO LEDS
LED
Function
POWER
Green: Power is applied to the device
Unlit: No power is applied to the device or
improper power source
ETH 1
Main/Primary Ethernet port indicator
Once lit, blinking indicates Ethernet activity
Green: 10/100BaseTX link
ETH 2
Auxiliary/Secondary Ethernet port
indicator
Once lit, blinking indicates Ethernet activity
Green: 10/100BaseTX link
Radio scanning: LEDs light in an ascending
sequence to indicate that the radio is
scanning
Radio registered: LEDs light to indicate the
RSSI level at the device.
Reserved for future release
RSSI
> -60
dBm
-70 dBm
< RSSI ≤
-60 dBm
-80 dBm
< RSSI ≤
-70 dBm
RSSI
≤ -80
dBm
