Table 95 AP Wireless Link Test attributes
AP Ping page
Use the AP Ping page to conduct a simple test of AP IP connectivity to other devices which are
reachable from the network. If no ping response is received or if “Destination Host Unreachable” is
reported, the target may be down, there may be no route back to the AP, or there may be a failure
in the network hardware (i.e. DNS server failure).
Enter the MAC Address of one of the connected SMs or simply click the
Select button of the SM desired in the “Registered Subscriber Modules”
list.
Choose the Packet Size to use for the throughput test.
Choose the time duration in seconds to use for the throughput test.
Uplink Antenna Selection specifies the antenna to be used in the uplink
for the wireless link test. The antenna cannot be forced if it is already
configured to Forced Sector Antenna or Forced Smart Antenna in
section Configuration > Radio.
This field indicates the result of the throughput test on the downlink, in
Mbps.
This field indicates the result of the throughput test on the uplink, in
Mbps.
This field indicates the result of the aggregate throughput on the link, in
Mbps. Displayed only when Downlink/Uplink Ratio is set to 75/25, 50/50
or 30/70.
Registered
Subscriber Modules
Use the Registered Subscriber Modules table to monitor registered SMs
and their key RF status and statistics information. Click Select on the SM
that is desired to be used in the throughput test.
