PAGE 1-4
Table 2 Main characteristics of the Force 300-25 Series
Force 300-16
Force 300-16 is a rugged high-capacity outdoor point-to point link
wireless device in the unlicensed 5 GHz frequency
bands with a
maximum UDP
throughput of 500+ Mbps (when operating
with 80 MHz
channel bandwidth). It is capable of operating in line-of-
sight (LOS) and
near-LOS conditions. Force 300-16 is available as an
integrated unit with
a dual-polarized 16 dBi integrated antenna.
Force 300-16 is based on highly-integrated wireless semiconductor
components designed to meet the IEEE 802.11ac standard, however the
Force 300-16 device has a proprietary air interface for the main point-
to-point link.
Force 300-16 is powered by standard power-over-Ethernet to a
1000Base-T port.
Management of the unit is conducted via the same interface as the bridged traffic (in-band
Management).
A summary of the main Force 300-16 characteristics is listed under Table 3.
