Cambium Networks ePMP 3000 Series User Manual

CHAPTER 2: SYSTEM HARDWARE
EPMP 3000 ACCESS POINT
PAGE 2-8
CABLE, UL POWER SUPPLY CORD SET, UK
N000900L009
CABLE, UL POWER SUPPLY CORD SET, US
N000900L007
ePMP 3000 Access Point mounting bracket
The ePMP 3000 Access Point module is designed
to be pole-mounted using the mounting bracket
provided in the box with the radio.
Figure 5 ePMP 3000 Access Point module
mounting bracket
ePMP 3000 Access Point Interfaces
The Ethernet port is located on the bottom of the unit. This interface is described in Table 6.
Table 6 ePMP 3000 Series rear interfaces
Port name
Connector
Interface
Description
Eth
RJ45
PoE input
Power over Ethernet (PoE)
100/1000BASE-T Ethernet
Data
SFP
SFP
Optical or Copper Gigabit
Ethernet
Management and/or data
ePMP 3000 Access Point specifications

Cambium Networks ePMP 3000 Series Specifications

General

Brand	Cambium Networks
Model	ePMP 3000 Series
Category	Wireless Access Point
Language	English
