Cambium Networks ePMP 3000 Series User Manual

CHAPTER 4: USING THE DEVICE
MANAGEMENT INTERFACE
CONNECTING TO THE UNIT
PAGE 4-4
6
Click OK, then click Close
Connecting to the PC and powering up
Use this procedure to connect a management PC directly to the ePMP for configuration and alignment
purposes and to power up the ePMP device.
Procedure:
1
Check that the device and power supply are correctly connected (the device Ethernet port is
connected to the power supply Ethernet power port
2
Connect the PC Ethernet port to the LAN ( port of the
power supply using a standard (not crossed) Ethernet cable.
3
Apply mains or battery power to the power supply. The green Power LED must illuminate
continuously.
Note If the Power and Ethernet LEDs do not illuminate correctly, see Testing hardware
on page 5-4.
