Cambium Networks ePMP 3000 Series User Manual

CHAPTER 2: SYSTEM HARDWARE
FORCE 300-25
PAGE 2-16
14° F (-10° C)
2 minutes, 30 seconds
Force 300-25 wind loading
Ensure that the device and the structure on which it is mounted are capable of withstanding the
prevalent wind speeds at a proposed ePMP site. Wind speed statistics are available from national
meteorological offices.
The device and its mounting bracket are capable of withstanding wind speeds of up to 200 kph
(124 mph).
Wind blowing on the device will subject the mounting structure to significant lateral force. The
magnitude of the force depends on both wind strength and surface area of the device. Wind loading is
estimated using the following formulae:
Force (in kilograms) = 0.1045aV
2
Where:
Is:
a
surface area in square meters
V
wind speed in meters per second
Force (in pounds) = 0.0042Av
2
Where:
Is:
A
surface area in square feet
v
wind speed in miles per hour
Applying these formulae to the ePMP device at different wind speeds, the resulting wind loadings are
shown in Table 18 and Table 19.
Table 18 Force 300-25 wind loading (Kg)
Type of ePMP
device
Largest
surface area
(square meters)
Wind speed (meters per
second)
30
40
50
Force 300-25
Integrated
0.09
16 Kg
28.4 Kg
44.4 Kg
Table 19 Force 300-25 wind loading (lb)
Type of ePMP device
Largest surface
area (square
feet)
Wind speed (miles per hour)
80
100
120
Force 300-25
Integrated
1.87
50.3 lb
78.5 lb
113.1 lb
