CHAPTER 2: SYSTEM HARDWARE
PAGE 2-20
CABLE, UL POWER SUPPLY CORD SET, INDIA
CABLE, UL POWER SUPPLY CORD SET, UK
CABLE, UL POWER SUPPLY CORD SET, US
Force 300-16 Interfaces
The Ethernet port is located on the rear of the integrated unit.
Table 22 Force 300-16 Series rear interfaces
Power over Ethernet (PoE).
Force 300-16 specifications
The Force 300-16 integrated module conforms to the specifications listed in Table 23 and Table 24.
The integrated module meets the low level static discharge specifications identified in Electromagnetic
compatibility (EMC) compliance on page 6-71 and provides internal surge suppression but does not
provide lightning suppression.
Table 23 Force 300-16 physical specifications
Dimensions (Diameter x Depth)
12.4 cm x 25.1 cm x 11.9 cm (4.9 in x 9.9 in x 4.7 in) with
mounting bracket
0.5 kg (1.1 lbs) with mounting bracket
Table 24 Force 300-16 environmental specifications
-30°C (-22°F) to +60°C (140°F)
