CHAPTER 2: SYSTEM HARDWARE
PAGE 2-14
CABLE, UL POWER SUPPLY CORD SET, CHINA
CABLE, UL POWER SUPPLY CORD SET, EU
CABLE, UL POWER SUPPLY CORD SET, INDIA
CABLE, UL POWER SUPPLY CORD SET, UK
CABLE, UL POWER SUPPLY CORD SET, US
Force 300-25 mounting bracket
The Force 300-25 module is
designed to be pole-mounted using
the mounting bracket provided in
the box with the radio.
Figure 7 Force 300-25 module mounting bracket
Force 300-25 Interfaces
The Ethernet port is located on the rear of the integrated unit. This interface is described in Table 14.
Table 14 Force 300-25 Series rear interfaces
Power over Ethernet (PoE).
