Page 24 - Manual FA01358-EN - 07/2019 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
F10
Output for
state-of-door
signal
The LED , connected to 10-5, signals the state of the door.
0 = Steady lit with door open and moving (default) / 1= Blinks intermittently -
every half second, during opening, and - every second, during closing. It stays
lit when the door is open and switches o when the door is closed.
F12 Soft Start
Upon each opening or closing command, the door starts slowly for a few
seconds.
OFF = Deactivated / ON = Activated (default)
F13 Closing thrust
At the closing limit-switch, the gear motor executes a brief closing thrust.
OFF = Deactivated (default) / 1 = minimum thrust / 2 =average thrust / 3
= maximum thrust
F14 Sensor type
Setting the type of accessory for controlling the operator.
0 = R700 for control with transponder sensor or magnetic card reader / 1
= R800 for control with the (default) keypad selector
F18 Additional light
Additional light connection output on 10-E.
Flashing light: it fl ashes during the door's opening and closing phases.
Cycle: it stays lit from the beginning of the opening until complete closing,
including the waiting time before the automatic closing.
Courtesy: it stays on for an adjustable time of between 60 and 180 seconds. To
set the time, see function F25.
0 = Flashing light (default) / 1 = Cycle / 2 = Courtesy
F19
Automatic
Closing Time
The automatic-closing wait starts when the opening limit switch point is reached
and can be set to between 1 and 180 seconds. The automatic closing does not
work if any of the safety devices trigger when an obstruction is detected, or
after a total stop, or during a power outage.
OFF = Deactivated (default) / 1 = 1 second /... / 180 = 180 seconds
F20
Automatic
closing time
after partial
opening
The wait before the automatic closing starts after a partial opening command
for an adjustable time of between 1 s and 180 s. The automatic closing does
not work if any of the safety devices trigger when an obstruction is detected, or
after a total stop, or during a power outage.
The F19 function must not be activated.
OFF = Deactivated (default) / 1 = 1 second /... / 180 = 180 seconds
F21
Pre-fl ashing
time
Adjusting the pre-fl ashing time for the fl ashing light connected to 10-E before
each maneuver. The fl ashing time is adjustable from one to ten seconds.
OFF = Deactivated (default) / 1 = 1 second /... / 10 = 10 seconds
F25
Courtesy light
time
The courtesy lamp stays lit for the necessary time while the door is opening
and closing.
It can be set to between 60 and 180 seconds.
60 = 60 seconds /... / 180 = 180 seconds (default)
F28
Speed of
opening
maneuver
Setting the door's opening speed, calculated as a percentage.
60 = minimum speed /… / 80 = 80% of the maximum speed (default) /… /
100 = maximum speed
F29
Speed of
closing
maneuver
Setting the door's closing speed, calculated as a percentage.
60 = 60% of the maximum speed /… / 80 = 80% of the maximum speed
(default) /… / 100 = 100% of the maximum speed
Page 24 - Manual FA01358-EN - 07/2019 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Original instructions
