Canon iPF671 - Page 164

Chapter 4
4-28
3) Remove ten screws [1], and then remove the rear cover [2].
F-4-62
4) Disconnect the connector [1].
F-4-63
5) Remove two screws [1], and then remove the maintenance cartridge holder unit [2].
F-4-64
[1]
[1] [1][2]
[1]
[1]
[2]
