Chapter 7
7-47
Print item Print content Printed value
CRREG HRZ A Adjustment value of the horizontal registration A and
B and C ink droplet landing position
HRZ B
HRZ C
VRT LATEST CALC POINTS As to the listed value, the number of effective value
from the first
VRT a Adjustment value when performing the vertical
registration a and b amd c average adjustment value
calculation
VRT b
VRT c
JOB LOG No Job history (up to 5 events) Number: Lowest is the most recent
M Print mode
HEAD Head height
TEMP&HUM Temperature and humidity
MEDIA TYPE Media type
DATE Date
TIME Time
R Registration condition A: The GAP used for printing and GAP of internal
registration adjustment value is a match.
B: The GAP used for printing and GAP of internal
registration adjustment value is a mismatch.
C: No registration adjustment value
GAP Gap information Distance between head and nedia
JOB NAME Job name
ADJUST LOG No No: Adjustment history (up to 5 events, lowest is the
most recent)
D: Advanced registration history
E: Expansion registration history
The history of D and E are each most recent one
only.
ADJ. TYPE Adjustment type manual: Manual adjustment
auto(d): Detail
auto(s): Basic
auto(e): Extension
HEAD Head height xx(y,Z)
xx= A: automatic panel setting, H: fixed panel
setting, AE: adjustment error occurred
(automatic), HE: adjustment error occurred
(fixed),
(y,z)=0: SLOW, 1: LO, 2: M1, 3: M2, 4: M3, 5:
H1
y: GAP1
z= GAP2
TEMP&HUM Temperature and humidity
MEDIA TYPE Media type
DATE Date
TIME Time
GAP1 1st kind GAP
GAP2 2nd kind GAP
DUTY UNIT: m2 A(xxx) A: Cumulative print area of Duty A
B: Cumulative print area of Duty B
C: Cumulative print area of Duty C
D: Cumulative print area of Duty D
E: Cumulative print area of Duty E
TTL: Cumulative print area of all Duty
xxx: Counter number of e-Maintenance/imageWARE
Remote
Unit: square/meter, square/feet, sheets (equivalent
of A4/LTR)
B(xxx)
C(xxx)
D(xxx)
E(xxx)
TTL(xxx)
UNIT: sq.f A(xxx)
B(xxx)
C(xxx)
D(xxx)
E(xxx)
TTL(xxx)
UNIT: A4
Sheet
A(xxx)
B(xxx)
C(xxx)
D(xxx)
E(xxx)
TTL(xxx)
UNIT: Letter
Sheet
A(xxx)
B(xxx)
C(xxx)
D(xxx)
E(xxx)
TTL(xxx)
