Chapter 1
1-39
Setting Item Description/Instructions
[Interface
Setup]
[EOP Timer] Specify the timeout period before cancellation of print jobs that cannot be
received by the printer.
[TCP/IP] [IPv4] [IPv4 Mode] Choose whether the printer IP address is configured automatically or a static IP
address is entered manually.
[Protocol] [DHCP]/
[BOOTP]/
[RARP]
Specify the protocol used to configure the IP address automatically.
[IPv4 Settings] [IP Address]/
[Subnet Mask]/
[Default G/W]
Specify the printer network information when using a static IP address.
Enter the IP address assigned to the printer, as well as the network subnet mask
and default gateway.
[DNS Settings] [DNS Dync
update]
Specify whether DNS server registration is updated automatically.
[Pri. DNS
SrvAddr]/[Sec.
DNS SrvAddr]
Specify the DNS server address.
[DNS Host
Name]
Specify the DNS host name.
[DNS Domain
Name]
Specify the DNS domain name.
[IPv6] [IPv6 Support] Set whether to support IPv6 connection.
[IPv6 StlessAddrs] Set whether to use IPv6 stateless address.
[DHCPv6] Set whether to use DHCPv6 setting.
[DNS Settings] [DNS Dync
update]-[Statefull
Addr]/[Stateless
Addr]
Specify whether DNS server registration is updated automatically.
[Pri. DNS
SrvAddr]/[Sec.
DNS SrvAddr]
Specify the DNS server address.
[DNS Host
Name]
Specify the DNS host name.
[DNS Domain
Name]
Specify the DNS domain name.
[Ethernet
Driver]*12
[Auto Detect] Specify the communication method. To apply your changes, choose Register
Setting.
Choose On for automatic configuration of the LAN communication protocol.
Choose Off to use settings values of Comm.Mode and Ethernet Type.
[Comm.Mode] Choose the LAN communication method.
[Ethernet Type] Choose the LAN transfer rate.
[Spanning Tree] Choose whether spanning-tree packets are supported over the LAN.
[MAC Address] Display the MAC address.
[Interface Print] Print the interface settings.
[Return Defaults] Select [OK] to return the [Interface Setup] settings to factory default.
