Fine-tuning the Print Position in the Vertical Direction ( Vertical
Adjust)
[Example] When printing on a tube (ø6.0 mm), the print position is shifted upward, so move
the print position downward by 0.5 mm.
ABCD
ABCD
Move the print position
downward by 0.5 mm.
1
Press the [Option] key.
2
Use [ ] or [ ] to select "Print adjust" and press the [Enter] key.
File
Print adjust
Setting
Option
3
Use [ ] or [ ] to select "VerticalPosition," and press the [Enter] key.
3ULQW

DGMXVW
Top position
VerticalPosition
Length
ɻ
4
Use [ ] or [ ] to select "Tube," and press the [Enter] key.
Vertical adjust
ShrinkTube
Label
Tube
5
Use [ ] or [ ] to select "ø6.0 mm" and press the [Enter] key.
Tube size
Љ5. 0ᶳ
Љ6. 0ᶳ
Љ6. 5ᶳ
Normal
Normal
Normal
