Canon MV950 - Components Guide

8
Components Guide
MV960/MV950/MV940/MV930
Left side view
Right side view
Lens cover switch ( 21, 85)
( open, closed)
LCD BACKLIGHT button ( 18)
Speaker ( 31)
CHARGE indicator ( 12) /
CARD access indicator ( 85, 89)
Memory card slot ( 81)
switch ( 4)
Grip belt (
16)
Terminal cover
AV terminal ( 32, 72, 75, 77)
USB terminal ( 97, 103)
DV terminal ( 70, 73, 80)
