Basic
Operations
39
Using
TV
with
SCART
Terminal
2
1.
Connect
yellow
plug
of
PC-150
SCART
Cable
to
camera’s
video
output
terminal,
and
connect
black
plug
to
camera’s
audio
output
terminal.
2.
Connect
other
end
of
SCART
Cable
to
SCART
terminal
of
TV.
O
To
Video
Terminal
(yellow)
0
To
Audio
Terminal
(black)
©
PC-150
O
To
SCART
Terminal
2
I
