AB722327DAH
ITEM
PART NO
PARTS NAME
SIZE
Q`TY
NOTE
0010
W
F061620
Flat W
asher
M6*φ1
6
2
0020
722318
Flat Scraping M
ovable
Seat
6061
1
0030
SJ
049100
Pan Head So
cket Screw
M4*0.
7*6
4
0040
BL21040
2
Liner Bearing
(C) LM12UU
4
0050
W
S060000
Spring W
asher
M6
6
0060
SR061100
Hex
. Socket Screw
M6
x55
2
0070
AB722615
B
Pressure Cyli
nder (Asm.)
1
0080
721306
Knob
1
0090
722331
Fixed Pl
ate
1
0100
W
F041010
Flat W
asher
M4*φ1
0*1.0t
2
