MAX370M
19
G. Zeroing
Zeroing refers to an axis initialization run during which the correct actual position is
determined by means of a reference signal. This procedure is referred to as homing,
referencing or calibration.
H. Conveyor
Enable conveyor motor.
I. Glue Heating
Heat up the glue pot to set temperature.
J. Workpiece detection
It turns green as workpiece is detected.
K. Feeding status
It is ready to feed next panel as light turns green.
L. Current temperature
Machine is ready to work when temperature reaches the setting value.
M. Set temperature
Press button M to change set temperature.
5.2 Edge feeding
Depending on the application, continuous edging coil from 0.4 mm to 3.0 mm can be glued to
panel materials up to 45 mm in thickness.
5.2.1 Feed coil edge
1. Put the edges through point A (guillotine).
2. Leave 0.5mm gap to the edge and fasten handles B & C.
3. Move plate to against edge and fasten handle D.
4. Make sure edge slide smoothly; if not, repeat step 2 &3.
