MAX370M
15
Check conveyor direction
1. Turn on the machine, press “Conveyer” on the control panel.
2. Ensure conveyor move forward. If the direction is incorrect, press
emergency stop bottom immediately and move to step 3 to swap wirings.
3. Turn off power and exchange two wires (choose random 2 wirings from L1,
L2, L3 to swap are equivalent to R, S, T).
4. Repeat step 1 and check chain in correct direction.
4.4 Connection of the dust suction system
Dust collectors are mainly designed for exhaustion from edge banding machines, which collects all
waste material is generated continuously during various operation.
