Cantek MX370M - Flush Trimming Unit; Clean Back Plates and Wheels; Replace Blades

MAX370M
38
6.5 Flush trimming unit
6.5.1 Clean back plates and wheels
Clean residue glue on back plates and wheels with proper solvent, such as cleaning naphtha
or WD40.
6.5.2 Replace blades
1. Turn the machine off and make sure it cannot be turned on again.
2. Remove the dust collecting hose. Then loosen the screws(A) and remove the dust collecting
cover. (Fig.6.5.A).
3. There are total four cutters. Use Allen key to loosen the screw for each specific
cutter(Fig.6.5.B).
4. Take the cutter out and replace a new one(Fig.6.5.C).
※NOTE: Make sure the direction is fit correctly (upper & lower are different) (Fig.6.5.D)
Fig.6.5.C
Fig.6.5.D
Fig.6.5.A
A
Fig.6.5.B
