※Note: Button(C) represents edge feeding timing.
Front feeding length is not in proper.
1. Check sensor that is located behind the conveyor. Clean wood-stick or dust, if necessary.
2. Change the edge infeed parameters from touch screen and test.
6.3 Clean glue pot
6.3.1 Usage tips
1. Heat up glue pot to 190degC (depends on glue specification) to melt the glue, then turn off
the power.
2. Wear gloves before doing any maintenance.
3. Use wooden stick or soft material to clean glue pot to avoid Teflon coating was scratched.
6.3.2 Remove glue pot
1. Loosen screw(A) and screw(B) (Fig 6.3.A).
2. Loosen the nut(D), and loosen the screw(C) (Fig 6.3.B).
And the edge feeding unit above the glue pot could thus be removed.
3. Go to backdoor, and unplug the connector (Fig 6.3.C).
4. Loosen the handle(E) and handle(F), and pull in the handle(G) toward the backdoor
