MAX370M
35
direction. And the chain(H) could thus been removed (Fig 6.3.D).
5. After above procedures, customer could take the glue pot away.
※ Note: When assembling the glue pot back, ensure the pin(I) is inserted into the groove and
thus the glue pot would be placed in the right position (Fig 6.3.E).
A
B
C
Fig. 6.3.A
Fig. 6.3.C
Fig. 6.3.D
G
E
F
H
C
D
Fig. 6.3.B
