6.10 Lubrication
6.10.1 Conveyor rail
1. Turn on the conveyor, then use grease gun with grease to lubricate the rail.
2. If there is no grease gun, stop the conveyor, pull up the chain pad and brush grease on the
feeding chain rail.
6.10.2 RFL system (regulator, filter, lubrication)
1. Make sure always use pneumatic oil. If use different types of oil, it can cause serious
damage.
2. Customer only needs to fill up the pneumatic, RFL system will do lubrication automatically.
3. We suggest that customer fills up to 80% oil when there is only 20% oil left in the
lubrication bottle.
※ Note: Before the action of filling up, remember to release air pressure first to prevent
oil from spraying out.
4. Check the liquid volume inside the filter bottle too when you are conducting step3. If liquid
capacity is over 50% in the filter bottle, customer has to pour out liquid.
