3. Machine Information
3.1 Specification
Model
MAX370M
Conveyor speed
7 M/min.
Panel thickness
12 - 45 mm
Edge thickness
0.4 - 3 mm
Min. panel width
90 mm
Min panel length
(12-30mm) 170 mm /
(30-45mm) 220mm
Working table height
856 mm
Extensible support width
560 mm
Extraction connector Ø in mm
Ø4" x 3
Total motor power
6.0kw-1PH ; 5.75 kw-3PH
Weight, kg (with standard equipment)
500kgs / 632kgs (N.W./G.W.)
Packing size (L x W x H)
2,920 x 720 x 1,320mm
End trimming/corner rounding
12,000 rpm
Flush trimming
10,500 rpm
Buffing
2,800 rpm
Pre-milling
12,000 rpm
Air consumption
250 L/min
Power (kw) of each motor
Feeding motor
0.75 (KW)
Pre-heating
0.125 (KW)
Glue pot heating
1.315 (KW)
Glue spindle motor
0.25 (KW)
End trimming/corner rounding motor
0.35 (KW)
Flush trimming motor
0.55 (KW)
Buffing unit motor
0.12 (KW) x 2 – 3Ph
0.18 (KW) x 2 – 1Ph
Pre-milling motor
1.5 (KW)
