Cantek MX370M - Flush Trimmer; Radius Scraper; Buffing Unit; Pre-Milling

MAX370M
49
7.7 Flush trimmer
Symptom
Possible Case
Solution
Cutterhead does
not rotate
1. Motor does not run.
2. Belt is loose/damage/broken.
1. Breaker trigger(QM4), refer to 6.12.2.
2. Check belt condition, replace if necessary.
Flush trimmer
does not trim
properly
1. Cutterhead does not properly adjusted.
2. Cutterhead is damaged.
3. Locating position is not accurate.
1. Adjust cutterhead.
2. Replace cutterhead.
3. Check digital readout and remove edge are the
same, if necessary, calibrate it. (Refer to 5.8.1)
7.8 Radius scraper
Symptom
Possible Case
Solution
Radius scraper
does not trim
properly
1. Cutterhead does not properly adjusted.
2. Cutterhead is damaged.
3. Locating position is not accurate.
1. Adjust cutterhead.
2. Replace cutterhead.
3. Check digital readout and remove edge are the
same, if necessary, calibrate it. (Refer to 5.9.1)
7.9 Buffing unit
Symptom
Possible Case
Solution
motor does not
rotate
1. Motor does not run.
1. Breaker trigger (QM5), refer to 6.12.2.
Buffing unit does
not polish
properly
1. Wheel does not properly adjusted.
2. Wheel is overspent..
1. Adjust wheel.
2. Replace wheel.
7.10 Pre-milling
Symptom
Possible Case
Solution
Cutterhead does
not rotate
1. Motor does not run.
1. Breaker trigger(QM6), refer to 6.12.2
Pre-milling does
not trim properly
1. Cutterhead does not properly adjusted.
2. Cutterhead is damaged.
3. Locating position is not accurate.
1. Adjust pre-milling readout.
2. Replace cutterhead.
3. Check digital readout and remove edge are the
same, if necessary, calibrate it. (Refer to 5.13.3)
7.11 Conveyor
Symptom
Possible Case
Solution
Conveyor does
not work
1. Motor does not run.
2. Door is open.
3. Dust or wood stuck.
1. Breaker trigger(QM1), refer to 6.12.2.
2. Close the door.
3. Remove wood and clean up.
