ITEM PART NO PARTS NAME SIZE Q`TY NOTE
0010 SR069300 Hex. Socket Screw M6*1*12 6
0030 720805 Adjustment Shaft 1
0040 AB720840 Thread Cylinder 1
0050 720803 Motor Fixed Plate 1
0060 722751B High Speed Motor MJ35B-350C 1 S,380V
0070 721071 Lock Nut (I) GUK10xP0.75 1
0080 722262 Digital Position Indicator 1
0100 AC722755D SEB-E370M 1 S
0110 KD060640 Parallel Key 6*6*40 1
0120 SR060400 Hex. Socket Screw M6*1*20 2
0130 WS060000 Spring Washer M6 8
0140 204263 Disc Washer φ10*φ20 3
0150 720846A Extension Bracket 1
0180 NH101700 Nut M10x1.5 1
0200 AC722751-2 Fillet Motor Wire Connector Set SEB-E370A CE 1 S,380V
9060 722751C High Speed Motor 1 S,220V
9200 AC722751A-2 Fillet Motor Wire Connector Set SEB-E370A CSA 1 S,220V
Notice: Following parts are optional, and not in the diagram.
To Next Page
