MAX370M
6
Location of machine
The machine is delivered with a thermal shrined nylon protection for transport, some parts of the
machine are detached.
Locate the machine in a suitable place, considering the overall dimensions of the machine, space
needed for stacking, loading and offloading work-pieces leaving sufficient space for the operator.
The machine base must be lay on a solid surface and well leveled.
Use a water level (or other good quality level) to check the working table is leveled in both directions.
Tolerance +- 0.25mm in longitudinal direction. It is possible to fix the machine to the floor by
screwing the 4 holes made on the bottom of the base.
Operator’s position
The operator’s position, can reach all operating and emergency controls with the maximum ease
and practicality.
The caution area in indicates the space which must be left free around the machine for cleaning
purposes, maintenance and normal use.
Noise Levels
As per ISO3744/94-ISO 7960/95 Annex norms:
When working with dust tractor
AVG 73.6 (dB (A)), OpE 73.1 (dB (A)) OpU 73.7 (dB(A))
Description of symbols:
AVG: Medium level of acoustic pressure
OpE Level of acoustic pressure of operator’s entrance place
OpU level of acoustic pressure of operator’s exit place
